LSMC1880TR-SP -- 18 Module Split Load c/w 100A Main Switch / 2x80A 30mA RCD +20/40kA DP SPD (11 useable ways)
++Description:++
Fitted with Double Pole 100/125A Main Switch . Supply with DP Type A RCD 63/80/100A 30mA for split load
Fitted with Single Module SPD 20/40kA Type 2
Metal Consumer unit enclosures supplied with blank, Neutral Cable, Busbar, Neutral & Earth Terminal bar, Din Rail, cable gland, busbar caps . Multiple circular cable entry knock-outs (25&32mm) on the top and bottom,32mm on the sides, and back plus larger slots
Large and accessible wiring space, with extra space for SPD, Main Switch, RCBOs,RCD, MCBs
Lockable lids. · Modern style finished in white polyester powder coating to RAL9010. · BSEN61439-3
Main Switch terminal capacity 100A is 35mm2 and 125A is 50mm2. · RCD terminal capacity is 25mm2 . SPD terminal capacity L is 16mm2 and N & E is 10mm2.
Mounting Type: IP40 Surface Mounted
Enclosure Type: Split Load with Main Switch SPD & RCDs
Dimensions (W x H x D): 388 × 270 × 110 mm
Weight: 19.7 kg
Code: LSMC1880TR-SP
| Brand | Liveelec |
