The Hager JK110 is a 100A, 10-way Type A SP&N (Single Phase and Neutral) distribution board from the Invicta 3 range. Designed primarily for commercial and industrial use, it features a robust surface-mounted steel enclosure with a light grey finish.
Key Specifications
Incomer: 100A 2-pole switch disconnector.
Outgoing Ways: 10 single-pole ways.
Enclosure: IP2XC rated steel with cable entry points on all sides and the back.
Dimensions: 236mm (H) x 326mm (W) x 125mm (D).
Compliance: Fully compliant with BS EN 61439-3 and the 18th Edition Wiring Regulations.
Features & Compatibility
Device Support: Specifically designed with ample wiring space to accommodate RCBOs and most consumer unit accessories.
Terminals: Includes a full complement of earth and neutral terminal bars, accepting up to 25mm²for incoming and 16mm² for outgoing cables.
| Surge Protection Included | No |
| Brand | Hager |
| Outgoing Ways | 10 Way |
| Incomer Current Rating | 100 A |
| Incomer Included | Yes |
| Pole Configuration | SP |
