The Redring RPS12 Powerstream is a 12kW unvented instantaneous water heater designed for point-of-use application, primarily for supplying hot water to hand basins in commercial or residential settings. This compact unit is energy-efficient, carrying an 'A' energy rating, and eliminates the need for long pipe runs from a central cylinder.
Key Specifications
Power Output: 12kW at 240V, with a current rating of 50A.
Flow Rate: Delivers approximately 4–6 litres per minute. It requires a minimum flow rate of 3.3 l/min to operate.
Operating Pressure: Supports a range of 0.7 to 10.3 bar (10–150 psi).
Dimensions: Measures 160mm (H) x 307mm (W) x 84mm (D).
Safety & Protection: Features an IPX4 rating for splash protection and includes two-stage thermal cut-out protection.
Installation & Usage
The RPS12 is highly flexible for installers, though it has specific application limits:
Orientation: The unique design allows for installation in four different orientations to fit varying pipework layouts.
Supported Outlets: It can supply up to two hand basins or one basin and a manual mixer shower (when used with the optional RM2 accessory).
Restrictions: It is not suitable for kitchen sinks (except for hand washing) and must never be used for filling a bath. It should not be used with thermostatically controlled taps.
Power Selection: There is an internal option at installation to disable one heating element, reducing the unit to half power (6kW) if required.
| Wattage | 12 KW |
| Brand | Redring |
